AXIS P5654-E Mk II PTZ Camera
This cost-effective PTZ camera offers great image quality in HDTV 1080p with 21x optical zoom and wide area coverage with 77° field of view. Thanks to Lightfinder 2.0 and Forensic WDR, it provides true colors and great detail in challenging light or near darkness. Including Axis Object Analytics, it can detect and classify people and vehicles- all tailored to specific needs. With IP66, NEMA 4X, and IK10 ratings, this robust and resistant camera can handle temperatures ranging from -30 °C to 50 °C (-22 °F to 122 °F). Furthermore, Axis Edge Vault safeguards your device and protects sensitive information from unauthorized access.
$2,464.63
Product Overview
This cost-effective PTZ camera offers great image quality in HDTV 1080p with 21x optical zoom and wide area coverage with 77° field of view. Thanks to Lightfinder 2.0 and Forensic WDR, it provides true colors and great detail in challenging light or near darkness. Including Axis Object Analytics, it can detect and classify people and vehicles- all tailored to specific needs. With IP66, NEMA 4X, and IK10 ratings, this robust and resistant camera can handle temperatures ranging from -30 °C to 50 °C (-22 °F to 122 °F). Furthermore, Axis Edge Vault safeguards your device and protects sensitive information from unauthorized access.
Main Features
- Axis Edge Vault safeguards the device
- HDTV 1080p with 21x optical zoom
- Lightfinder 2.0 and Forensic WDR
- Support for advanced analytics
- Wide 77° field of view
General Information
Name: AXIS P5654-E Mk II PTZ IP Camera, HDTV 1080p with 21x Optical Zoom, 4-84.6mm Lens, 60 Hz
Category: Axis Communications, Video Surveillance, IP Cameras, PTZ Security Cameras
UPC Code: 7331021086272
Country of Origin: Mexico. Country of origin is subject to change.
General Information
| Brand Name | AXIS Communications | ||
| Manufacturer Part Number | 02915-001 | Product Line | P |
| Product Name | AXIS P5654-E Mk II 60 Hz | Product Series | P56 |
| Product Type | PTZ cameras | Supported Protocols | IPv6 USGv6, NIST SP500-267 |
Technical Information
| Aperture | f/1.6–4.5 | Resolution | 4MP |
| Lens Type | Varifocal | Max Frame Rate | 60 fps |
| Optical Zoom | 21x | Night Vision | Yes |
| Min Focal Length | 4mm | Video Formats | H.264 / H.265 |
Camera
| Sensor Type | CMOS | Wide Dynamic Range | Yes |
Certifications
| IP Rating | IP66 | TAA Compliant | Yes |
Display & Graphics
| Sensor Size | 1/2.8″ | Max Resolution | 1920 x 1080 |
Environmental Conditions
| Max Temp | 122°F (50°C) | Min Temp | -22°F (-30°C) |
Exposure
| Min Illumination | 0.01 lux |
Lens
| Focal Length | 4.0–84.6mm | Max Focal Length | 84.6mm |
Memory
| SD Card Support | Yes |
Others
| ADI Part Number Replaces | Z4-01759001 | Model Replaces | 01759-001, P5654-E |
Physical Characteristics
| Color | White | Form Factor | Dome |
| Weight | 5.51 lb | Durability | Waterproof, Impact Resistant, Shock Resistant |
Power
| Input Voltage | 240V AC | Max Power | 16W |
| PoE | Yes |
Product Information
| Diameter | 5.9″ | Mount Type | Ceiling Mount |
Warranty
| Warranty | 5 Years |
Miscellaneous
| Certifications |
CISPR 32 Class A, CISPR 35, EAC, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Certifications & Standards | ONVIF G, ONVIF M, ONVIF S, ONVIF T |
| Country of Origin | MX |
| Environmental Certification |
IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X |
| Features |
Auto Tracking, Day/Night, Defog, HTTPS Encryption, Human Detection, Privacy Masking, Vehicle Detection, White Balance, Wide Dynamic Range |
| Impact Protection Rating | IK10 |
| Indoor/Outdoor | Outdoor |
